TIGER 1200 RALLY EXPLORER
Loading your ride
With world-beating comfort and all-road capability, the top-of-the-range Rally Explorer is the ultimate large capacity adventure motorcycle.
SPECIFICATION
| Feature | Details |
|---|---|
| Price | |
| Body Price | From MYR 130,000.00 |
| Feature | Details |
|---|---|
| Engine & Transmission | |
| Type | Liquid-cooled, 12 valve, DOHC, inline 3-cylinder |
| Capacity | 1160 cc |
| Bore | 90.0 mm |
| Stroke | 60.7 mm |
| Compression | 13.2:1 |
| Max Power EC | 150PS / 148bhp (110.4kW) @ 9,000rpm (100PS rain mode) |
| Max Torque EC | 130 Nm @ 7,000 rpm |
| System | Multipoint sequential electronic fuel injection with electronic throttle control |
| Exhaust | Stainless steel 3 into 1 header system with underslung primary silencer and side mounted secondary silencer |
| Final Drive | Shaft drive |
| Clutch | Hydraulic, wet, multi-plate, slip and assist |
| Gearbox | 6 speed |
| Feature | Details |
|---|---|
| Chassis | |
| Frame | Tubular steel frame, with forged aluminium outriggers. Fabricated, bolt-on aluminium rear subframe. |
| Swingarm | Twin sided "Tri-Link" aluminium swingarm with twin aluminium torque arms. |
| Front Wheel | Spoked (Tubeless). 21 x 2.15in. |
| Rear Wheel | Spoked (Tubeless). 18 x 4.25in. |
| Front Tyre | Metzeler Karoo Street, 90/90-21 (M/C 54V TL) |
| Rear Tyre | Metzeler Karoo Street, 150/70R18 (M/C 70V TL) |
| Front Suspension | Showa 49mm, semi-active damping USD forks. 220mm travel. |
| Rear Suspension | 220mm wheel travel Showa semi-active damping monoshock, with automatic electronic preload adjustment and New Active Preload Reduction feature. Depending on the combined weight of rider, pillion and luggage, this feature could lower the riding height by up to 20mm when the motorcycle comes to a standstill, offering greater ease and confidence. |
| Front Brakes | Brembo M4.30 Stylema monoblock radial calipers, OC-ABS, twin 320mm floating discs. Magura HC1 span adjustable radial master cylinder with separate reservoir. |
| Rear Brakes | Brembo single piston caliper, OC-ABS, single 282mm disc. Rear master cylinder with remote reservoir. |
| Instrument Display and Functions | Full-colour 7” TFT instrument pack with My Triumph Connectivity System |
| Feature | Details |
|---|---|
| Dimensions & Weights | |
| Width Handlebars | Handlebars 849mm, handguards 982 mm |
| Height Without Mirror | Low screen 1490mm, high screen 1547 mm |
| Seat Height | Adjustable 875/895 mm |
| Wheelbase | 1560 mm |
| Rake | 23.7 º |
| Trail | 112 mm |
| Tank Capacity | 30 L |
| Wet Weight | 262kg (90% fuel - mass in running order) kg |
| Feature | Details |
|---|---|
| Fuel Consumption | |
| Fuel Consumption | 5.1 l/100km mpg |
| CO2 Figures | 119 g/km EURO 5 Regulation (EU) No. 134/2014 Annex VIII g/km |
| Feature | Details |
|---|---|
| Service | |
| Service Interval | 10,000 miles/16,000 km or 12 months, whichever comes first |
FEATURES
|
CHASSIS
|
|
|---|---|
| Wheels | 21" Front / 18" rear lightweight tubeless spoked wheels |
| Fuel Tank | 30 litre aluminium fuel tank |
| Centre Stand | Included |
| Showa Semi-Active Suspension | 220mm travel Showa Semi Active Suspension now with New Active Preload Reduction feature. Depending on the combined weight of rider, pillion and luggage, this feature could lower the riding height by up to 20mm when the motorcycle comes to a standstill, offering greater ease and confidence. |
|
TECHNOLOGY
|
|
| Blind Spot Radar | Included |
| Cruise Control | Included |
| Shift Assist | Triumph shift assist (up and down) |
| Hill Hold | Included |
| Riding Modes | 6 |
| Tyre Pressure Monitoring System | Included |
| Adaptive Cornering Lighting | Included |
| All-LED Lighting with Daytime Running Light | Included |
| LED Auxiliary Lights | Included |
| 7 inch TFT instruments with My Triumph Connectivity System | Included |
| ABS and Traction Control | Included |
|
RIDER COMFORT
|
|
| Protection |
Hand guards, aluminium sump guard with moulded upper, engine protection bars, fuel tank protection bars |
| Heated Grips | Included |
| Heated Rider and Pillion Seats | Included |
|
WARRANTY
|
|
| Warranty | 3 years, unlimited mileage warranty |
|
CHASSIS
|
|
|---|---|
| Wheels | 21" Front / 18" rear lightweight tubeless spoked wheels |
| Fuel Tank | 30 litre aluminium fuel tank |
| Centre Stand | Included |
| Showa Semi-Active Suspension | 220mm travel Showa Semi Active Suspension now with New Active Preload Reduction feature. Depending on the combined weight of rider, pillion and luggage, this feature could lower the riding height by up to 20mm when the motorcycle comes to a standstill, offering greater ease and confidence. |
|
TECHNOLOGY
|
|
| Blind Spot Radar | Included |
| Cruise Control | Included |
| Shift Assist | Triumph shift assist (up and down) |
| Hill Hold | Included |
| Riding Modes | 6 |
| Tyre Pressure Monitoring System | Included |
| Adaptive Cornering Lighting | Included |
| All-LED Lighting with Daytime Running Light | Included |
| LED Auxiliary Lights | Included |
| 7 inch TFT instruments with My Triumph Connectivity System | Included |
| ABS and Traction Control | Included |
|
RIDER COMFORT
|
|
| Protection |
Hand guards, aluminium sump guard with moulded upper, engine protection bars, fuel tank protection bars |
| Heated Grips | Included |
| Heated Rider and Pillion Seats | Included |
|
WARRANTY
|
|
| Warranty | 3 years, unlimited mileage warranty |
MORE ADVANCED AND REFINED
For 2024, Tiger 1200 Rally Explorer has been significantly updated to be more advanced and refined than ever. Featuring improved low speed control, with enhanced comfort and ergonomics.
ACTIVE PRELOAD REDUCTION
In addition to the adjustable seat height of 875-895mm, the Active Preload Reduction feature can further lower the bike by up to 20mm when coming to a stop, depending on the combined weight of rider, pillion and luggage.
ENGINE
Whether you are riding on or off road, the updated T-plane delivers more refinement and better low speed precision and control, via increased inertia, improved balance and revised calibration.
30-LITRE FUEL TANK
The Rally Explorer’s 30-litre fuel tank gives 50% more range than the Rally Pro. The extra weight is carried low to retain the exceptional low-speed balance and manoeuvrability.
BLIND-SPOT RADAR
A major safety innovation developed in partnership with Continental, the Rally Explorer benefits from an rear-mounted radar that gives you both Blind Spot Assist and Lane Change Assist features.
ALL-ROAD WHEELS AND SUSPENSION
A 21” front wheel combines with Showa semi-active suspension with 220mm of travel for total control on the most testing terrain. The system automatically adjusts to load and surface for no compromise handling.
HEATED RIDER AND PILLION SEATS
The Rally Explorer is fitted with heated rider and pillion seats as standard for all-weather comfort on long journeys, with multiple temperature settings and independent rider and pillion adjustment.
TYRE PRESSURE MONITORING SYSTEM
Standard fit on the Rally Explorer for enhanced rider safety and convenience, the Tyre Pressure Monitoring System (TPMS) delivers real-time information and rider peace of mind.
CORNERING ABS AND TRACTION CONTROL
Controlled by a sophisticated IMU, the Optimised Cornering ABS and Traction Control systems bring enhanced control in all riding situations. Both can be switched off for expert off-road riding.
PREMIUM SPEC BRAKES
Class-leading Brembo Stylema calipers are paired to a Magura master cylinder for advanced braking power and finesse. Switchable ABS enhances on-road safety and off-road control.
COMFORT AND CONVENIENCE
The Rally Explorer is packed with technology for maximum enjoyment of every ride. Highlights include heated grips and seats, cruise control and under-seat storage with a USB charging point.
